Process Analysis Toolkit (PAT) is developed by Semantic Engineering (SemEng). It is a self-contained framework for simulating and verifying real-time, concurrent, and probabilistic systems.

Introduction


PAT is a self-contained framework for to support composing, simulating and reasoning of concurrent, real-time systems and other possible domains. It comes with user friendly interfaces, featured model editor and animated simulator. Most importantly, PAT implements various model checking techniques catering for different properties such as deadlock-freeness, divergence-freeness, reachability, LTL properties with fairness assumptions, refinement checking and probabilistic model checking. To achieve good performance, advanced optimization techniques are implemented in PAT, e.g. partial order reduction, symmetry reduction, process counter abstraction, parallel model checking. So far, PAT has 4370+ registered users from 1341+ organizations in 150 countries and regions.

Screenshot:

PAT screenshot

The main functionalities of PAT are listed as follows:

  • User friendly editing environment (multi-document, multi-language, I18N GUI and advanced syntax editing features) for introducing models
  • User friendly simulator for interactively and visually simulating system behaviors; by random simulation, user-guided step-by-step simulation, complete state graph generation, trace playback, counterexample visualization, etc.
  • Easy verification for deadlock-freeness analysis, reachability analysis, state/event linear temporal logic checking (with or with fairness) and refinement checking.
  • A wide range of built-in examples ranging from benchmark systems to newly developed algorithms/protocols.

We design PAT as an extensible and modularized framework, which allows user to build customized model checkers easily. We provide a library of model checking algorithms as well as the support for customizing language syntax, semantics, model checking algorithms and reduction techniques, graphic user interfaces, and domain specific abstraction techniques. Delightfully, PAT has been growing up to eleven modules today to deal with problems in different domains including Real Time Systems, Web Service Models, Probability Models, and Sensor Networks etc. In order to be state-of-the-art, we are actively developing PAT to cope with latest formal-automated system analysis techniques.

We have been using PAT to model and verify a variety of systems. Ranging from recently proposed distributed algorithms, security protocols to real-world systems like multi-lift and pacemaker systems. Previously unknown bugs have been discovered. The Post to Post Links II error: No post found with slug "experiments" results show that PAT is capable of verifying systems with large number of states and outperforms the popular model checkers in some cases. We have successfully demonstrated PAT as an analyzer for process algebras in the 30th International Conference on Software Engineering (ICSE 2008), the 21st International Conference on Computer Aided Verification (CAV 2009), International Symposium on the Foundations of Software Engineering (FSE 2010), and the 22nd annual International Symposium on Software Reliability Engineering (ISSRE 2011).

20 Year ICFEM Most Influential System Award


    3 founders Jun, Yang and Jin Song have been awarded the 20 Year ICFEM Most Influential System Award for developing the PAT verification system. The award was presented by the ICFEM founder Prof. Shaoying Liu (FIEEE) at 20th ICFEM on 14 Nov 2018.

    Sir Tony C.A.R. Hoare (Turing Award) was awarded the 20 Year ICFEM Most Influential Person Award. Prof. Michael Butler was awarded 20 Year ICFEM Outstanding Service Award.

    PAT Award

System Design


System Architecture

Starting from version 3.5, PAT is developed to be a generic framework, which can be easily extended to support new modeling languages or new assertion languages (as well as dedicated verification algorithms). The system architecture is shown in the following figure.

PAT Arch

In PAT, each language is encapsulated as one module with predefined APIs, which identify the (specialized) language syntax, well-formness rules as well as (operational) formal semantics, and loaded at run time according to the input model. This architecture allows new languages to be developed easily by providing the syntax rules and semantics. Three modules have been developed currently, namely Communicating Sequential Processes (CSP) module, Real-Time System (RTS) Module and Web Service (WS) module. An extensible library of assertions, together with their verification algorithms, have been designed to operate on the underlying shared semantic models of the modules and therefore easily applicable to all modules. For instance, the automata-based LTL model checking algorithm, with partial order reduction, is applied to allmodules.

System Components

The following are the four main components of PAT.

  • Editor: User friendly editing envinronment (with advanced syntax editing features) for introducing models.
  • Parser: Smart parsing to apply process equivalence laws to simply system models as well as associating assertions with the dedicated checker.
  • Simulator: User friendly simulator for interactively and visually simulating system behaviors; by either random simulation, user-guided step-by-step simulation, complete state graph generation, trace playback, counterexample visualization, etc.
  • Model Checkers: Click button model checker for deadlock-freeness verification, reachability analysis, state/event linear temporal logic verification (with or with fairness) and refinement checking (with or without checking data components).

PAT Flow

The above highlights the work flow of PAT. The parser takes in the system model and then builds the internal representation. Different assertions are associated with the dedicated analyzers respectively. If the assertion involves LTL, it is automatically translated into an equivalent Buchi automaton. The internal representaion of the model can be fed to the simulator for simulation or the verifiers for verification. If a counterexample is generated, the counterexample may be fed to the simulator.

Software Components

PAT is implemented using C# 4.0 and Visual Studio 2010. The following external components are used or embedded in the PAT package.

  • PAT’s parser is based on Antlr Parser Generator.
  • The LTL to Buchi Automata Converter in PAT is based on Paul Gastin’s work on fast translation from LTL to Buchi automata. We have translated the original c++ code to C#.
  • PAT’s editor (i.e., mulit-document environment) is based on dotnetfireball.
  • PAT’s unit testing component is done using NUnit.
  • PAT is formally verified by Contracts and Spec#.

N-PAT: A Nested Model Checker


N-PAT implements a novel concept of nested model checking where a model may contain placeholders to be instantiated by the verification results of sub-models.

Download and documentation.

Conference Paper. Preprint. BibTex.

Customers


PAT Customers

Publications


    When you cite PAT, please use our CAV 09 paper: PAT: Towards Flexible Verification under Fairness. (Bib)
